Insect Screen Specifications for Architects & Builders
Do it once, do it right.
Insect screen specifications for architects and builders - product data, finishes and warranty terms. Made to measure and installed by our own team.
★ 4.9 · 3,000+ homes · 25+ years
Detailing across the range
A few installs showing cassette, side-channel, postless-corner, recessing, and motorisation detail as specified.
-
Retrofit detailing to existing joinery
-
Postless corner - screens meet with no corner post
-
Recessed into the structure, colour-matched side tracks
Specification support for your project
Phantom Screens New Zealand works with architects, designers, and builders to specify retractable insect screens for doors or windows, and patio or outdoor blinds. We can be involved from concept or detail design, advising on span limits, recesses, wiring, and specifications so the screens integrate cleanly into the build.
Product data and downloads
Each system has its own span limits, cassette sizes, and mesh or fabric options. Specification and product brochures for each system are available to download below. CAD, 3D models, Revit/BIM families, and NZ-specific metric drawings are available on request - contact us with your project. The door screens, window screens, and outdoor blinds pages cover the consumer-facing detail.
Installation and detailing
Most installs are retrofitted to existing joinery, but on new builds we coordinate recessed cassette and side-channel details with your joiner or builder, and wiring runs for motorised outdoor blinds with your electrician. For frameless corner openings the Brio bi-fold can meet without a corner post, and cassettes can be recessed into a prepared cavity so the hardware sits flush - recessed-cavity and carriage-support drawings are in the downloads below.
Finishes and warranty
Hardware is typically powder-coated in the Dulux range - 20 standard colours, or a custom match for a small surcharge. See the colour options guide for the standard range; Screens we make carry a limited lifetime parts warranty plus 24 months on labour; motors are covered for 5 years, electricals and remotes for 1 year. Mesh is a wear item and excluded, but it is replaceable and serviceable. Supplier-made products we install, such as the Allegion Brio 612, carry Allegion’s warranty rather than ours. All of this sits alongside the Consumer Guarantees Act, and specific terms for a specified or commercial job are available on request.
Detailing options
Phantom Wall Screen and MeshLock retractable screens carry a few detailing options specified at order. The latch stop - the slide-bar latch that holds the screen closed - can sit front-of-slidebar or back-of-slidebar to suit how the screen meets the jamb or a paired screen, with the plastic component colour matched to the hardware. For most openings the standard configuration is what we fit; where a particular layout needs it, note the detail with your order or send it through and we will confirm at the measure-up.
Talk to us about a specification
Send your project details and drawings through the quote form and note that it is a specification enquiry - we will route it to the right person.
Specifications
- Product data
- Span limits, cassette sizes, mesh and fabric options per system
- Installation
- Retrofit and recessed/new-build detailing, coordinated with trades
- Finish
- Powder-coat colour-matched to the Dulux range or project requirements.
- Motorisation
- Alpha motors as standard in our Executive screens (SIMU or Somfy on request) (sensors + home automation), wiring coordinated on site.
- Warranty
- Limited lifetime on Phantom-made screens; supplier products (e.g. Brio) carry the manufacturer's warranty
Full details: Phantom Door Screens spec sheet (PDF) Serene window screen spec sheet (PDF) Executive motorised screen spec sheet (PDF) Mesh selection guide (PDF) Brio 612 pleated spec sheet (PDF)
Serene Window Screen
Manufacturer BIM/CAD assets from the global Phantom technical library. NZ-specific specifications and metric drawings on request.
| Document | Type | Size | Download |
|---|---|---|---|
| Serene Window Screen 3D Model3D CAD model (DWG) for specifiers. | 3D model (DWG) | 106 KB | Download Serene Window Screen 3D Model (3D model (DWG), 106 KB) |
| Serene Window Screen Revit/BIM FamiliesRevit family files (RFA) for BIM workflows, zipped. | 3D model (ZIP) | 5.9 MB | Download Serene Window Screen Revit/BIM Families (3D model (ZIP), 5.9 MB) |
| Serene Design Specification Detail View 2014 | Specification (PDF) | 324 KB | Download Serene Design Specification Detail View 2014 (Specification (PDF), 324 KB) |
| Serene Design Specification External View 2014 | Specification (PDF) | 271 KB | Download Serene Design Specification External View 2014 (Specification (PDF), 271 KB) |
Executive Motorised Screen
Manufacturer BIM/CAD assets from the global Phantom technical library. NZ-specific specifications, metric and 230V detailing on request.
| Document | Type | Size | Download |
|---|---|---|---|
| Executive Motorised Screen Revit/BIM FamiliesRevit family files (RFA) for BIM workflows - surface, recessed and overhead motorized configurations, zipped. | 3D model (ZIP) | 16.9 MB | Download Executive Motorised Screen Revit/BIM Families (3D model (ZIP), 16.9 MB) |
| Alpha Motor CatalogueAlpha 45 mm tubular motors fitted to Executive screens - WSER50, WSEC50, WSERD50-B. 240 V / 50 Hz, 0.84-1.06 A, IP44. | Specification (PDF) | 9.4 MB | Download Alpha Motor Catalogue (Specification (PDF), 9.4 MB) |
| Executive Wind Force Guide | Specification (PDF) | 27 KB | Download Executive Wind Force Guide (Specification (PDF), 27 KB) |
| Motorized Screen Cable Guided Design Specification Assembled View | Specification (PDF) | 109 KB | Download Motorized Screen Cable Guided Design Specification Assembled View (Specification (PDF), 109 KB) |
| Motorized Screen Cable Guided Design Specification Exploded View | Specification (PDF) | 148 KB | Download Motorized Screen Cable Guided Design Specification Exploded View (Specification (PDF), 148 KB) |
| Recessed Cavity With Carriage Support Located | Specification (PDF) | 155 KB | Download Recessed Cavity With Carriage Support Located (Specification (PDF), 155 KB) |
| Recessed Executive Design Specification Assembled View | Specification (PDF) | 172 KB | Download Recessed Executive Design Specification Assembled View (Specification (PDF), 172 KB) |
| Recessed Executive Design Specification Exploded View | Specification (PDF) | 107 KB | Download Recessed Executive Design Specification Exploded View (Specification (PDF), 107 KB) |
| Standard Executive Design Specification Assembled View | Specification (PDF) | 455 KB | Download Standard Executive Design Specification Assembled View (Specification (PDF), 455 KB) |
| Standard Executive Design Specification Exploded View | Specification (PDF) | 104 KB | Download Standard Executive Design Specification Exploded View (Specification (PDF), 104 KB) |
MeshLock Door Screen
Manufacturer BIM/CAD assets from the global Phantom technical library. NZ-specific specifications and metric drawings on request.
| Document | Type | Size | Download |
|---|---|---|---|
| MeshLock Door Screen 3D Models3D CAD models (DWG) for specifiers, zipped. | 3D model (ZIP) | 99 KB | Download MeshLock Door Screen 3D Models (3D model (ZIP), 99 KB) |
| MeshLock Door Screen Revit/BIM FamiliesRevit family files (RFA) for BIM workflows, zipped. | 3D model (ZIP) | 17.7 MB | Download MeshLock Door Screen Revit/BIM Families (3D model (ZIP), 17.7 MB) |
Retractable Wall Screen
Manufacturer BIM/CAD assets from the global Phantom technical library. NZ-specific specifications and metric drawings on request.
| Document | Type | Size | Download |
|---|---|---|---|
| Retractable Wall Screen Revit/BIM FamilyRevit family file (RFA) for BIM workflows - manual wall screen. | 3D model (RFA) | 1.8 MB | Download Retractable Wall Screen Revit/BIM Family (3D model (RFA), 1.8 MB) |
| Retractable Wall Screen Detail View | Specification (PDF) | 264 KB | Download Retractable Wall Screen Detail View (Specification (PDF), 264 KB) |
| Retractable Wall Screen External Assembled View | Specification (PDF) | 216 KB | Download Retractable Wall Screen External Assembled View (Specification (PDF), 216 KB) |
Brio 612 Pleated Screen
Brio 612 is supplied by Allegion and carries Allegion's warranty, not Phantom's limited lifetime warranty. Assembled in Australia.
| Document | Type | Size | Download |
|---|---|---|---|
| Brio 612 CAD FilesCAD details for architects / specifiers. | CAD (ZIP) | 537 KB | Download Brio 612 CAD Files (CAD (ZIP), 537 KB) |
| Brio 612 High Performance Kit | Specification (PDF) | 1010 KB | Download Brio 612 High Performance Kit (Specification (PDF), 1010 KB) |
| Brio 612 Retractable Pleated Insect Screen Technical Sheet | Specification (PDF) | 966 KB | Download Brio 612 Retractable Pleated Insect Screen Technical Sheet (Specification (PDF), 966 KB) |
| Brio 612 Technical SpecificationsSpecifier dimensions + fixing detail. | Specification (PDF) | 966 KB | Download Brio 612 Technical Specifications (Specification (PDF), 966 KB) |
Ready for a quote?
Send photos and rough sizes for an indicative price - no visit needed. We only book a measure-up once you're happy with the solution and product.
Warranty by product
Phantom screens carry our limited lifetime warranty. Supplier-made products - the Allegion Brio 612, MagicSeal magnetics, and Ziptrak blinds - carry the manufacturer's warranty.
FAQ
Frequently asked questions
Do you provide CAD details or specification notes? +
Yes. We provide product data, span limits, and installation detailing for architects and builders, and can advise on recesses, wiring, and motorisation during concept or detail design. Contact us with your project and we will supply what you need.
Can you coordinate with our build programme? +
Yes. We coordinate recess and wiring details with joiners, builders, and electricians, and can stage installs to suit site access and handover.
What finishes and colours are available? +
Hardware is powder-coated and colour-matched to the Dulux range so screens integrate with the joinery and cladding you specify.
What are the warranty terms for specified jobs? +
Screens we make carry a limited lifetime parts warranty plus 24 months on labour, with motors covered for 5 years and electricals and remotes for 1 year. Mesh is a wear item and excluded, but replaceable and serviceable. Supplier-made products we install, such as the Allegion Brio 612, carry Allegion's warranty rather than ours. This sits alongside the Consumer Guarantees Act. Specific terms for a specified or commercial job can be provided on request.
Are you the same company as Phantom Screens in the US or Canada? +
Phantom Screens NZ is New Zealand owned and run, and part of the wider Phantom Screens family. Phantom in Canada leads much of the group's research and development, and a few of our door and outdoor ranges are made to measure by Phantom in Australia, where our New Zealand volumes are too low to make them here. Most of our screens are made to measure in our own Tauranga workshop.
